Bronze Filter Cartridges
- Custom to drawing or sample
- Uniform pore distribution
- Export packing
Manufactured in Shanghai by BROLERN with matched in-house tooling. Ratings, materials and dimensions are listed in the specification below — other geometries are available on request.
Tel +86 135 2411 1326 · WhatsApp +86 135 2411 1326
BROLERN sintered bronze cartridges use RoHS-compliant material. Moulds are complete and the process is stable and repeatable, keeping micro-pore distribution uniform. The media resists acid and alkali corrosion and reaches filtration ratings down to 0.5 µm, mainly for filtration and silencing of air, water and oil.
The family is widely used in pneumatics, chemical processing, food, pharmaceutical and environmental industries. Custom shapes are manufactured to customer drawings or samples.
Key specifications
| Material | Sintered copper / copper alloy (RoHS compliant) |
|---|---|
| Process | Micro-pore sintering moulding |
| Filtration rating | About 0.5 um |
| Size range | OD 1.0-200 mm, height 1-1700 mm; rods, tubes, sheets, special shapes |
| Applications | Air, water and oil filtration and silencing - pneumatics, chemical, food, pharmaceutical, environmental protection |
| Customization | Custom production from customer drawing or sample; sample quantities for validation |
Product shapes & size range
Product shape Product shape | Rods Rods | Tubes Tubes | Standard sheets Standard sheets | Others Others | ||||
Product size range Product size range Unit: mm | Outer dia. / side length Outer diameter / Side length | Height High | Outer dia. Outer diameter | Internal dia. internal diameter | Height High | Outer dia. / side length Outer diameter / Side length | Thickness Thick | All kinds of special-shaped products All kinds of special-shaped products |
Φ1.0~Φ200 | 1.5~1700 | Φ3.0~Φ200 | Φ1.5~Φ190 | 1.5~500 | Φ1.0~Φ200 | 1.0~80 | ||
Filtration rating Filtration accuracy | 0.5 μ~120 μ | Working temperature Operating temperature | -200℃~+600℃ | |||||
Photos
