Stainless Steel Filter Cartridges
- Custom to drawing or sample
- Uniform pore distribution
- Export packing
Manufactured in Shanghai by BROLERN with matched in-house tooling. Ratings, materials and dimensions are listed in the specification below — other geometries are available on request.
Tel +86 135 2411 1326 · WhatsApp +86 135 2411 1326
BROLERN sintered stainless steel cartridges use multi-layer sintered mesh with RoHS-compliant material. Pore distribution is uniform, the media resists acid and alkali corrosion, and ratings reach 0.5 µm - primarily for filtration and silencing of air, water and oil in demanding duty.
Typical applications cover pneumatics, chemical processing, food, pharmaceutical and environmental industries. Cartridges are manufactured to customer drawings or samples.
Key specifications
| Material | Multi-layer sintered stainless steel mesh (RoHS compliant) |
|---|---|
| Process | Sintered mesh forming |
| Filtration rating | 2-200 um particle range; ratings to 0.5 um |
| Size range | OD 1.0-200 mm; rods, tubes, sheets, special shapes |
| Applications | Chemical, food, pharmaceutical and environmental process filtration |
| Customization | Custom production from customer drawing or sample; sample quantities for validation |
Product shapes & size range
Product shape Product shape | Rods Rods | Tubes Tubes | Standard sheets Standard sheets | Others Others | ||||
Product size range Product size range Unit: mm | Outer dia. / side length Outer diameter / Side length | Height High | Outer dia. Outer diameter | Internal dia. internal diameter | Height High | Outer dia. / side length Outer diameter / Side length | Thickness Thick | All kinds of special-shaped products All kinds of special-shaped products |
Φ1.0~Φ200 | 1.5~1700 | Φ3.0~Φ200 | Φ1.5~Φ190 | 1.5~500 | Φ1.0~Φ200 | 1.0~80 | ||
Filtration rating Filtration accuracy | 0.5 μ~120 μ | Working temperature Operating temperature | -200℃~+800℃ | |||||
Photos
